(6/9)

INDUC

T

O

RS

20160128 / inductor_commercial_power_vls252012e_en.fm

Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.

Please note that the contents may change without any prior notice due to reasons such as upgrading.

＊

VLS252012E Type

ELECTRICAL CHARACTERISTICS

CHARACTERISTICS SPECIFICATION TABLE

Idc1: When based on the inductance change rate (30% below the nominal value)

Idc2: When based on the temperature increase (Temperature increase of 40°C by self heating)

○ Measurement equipment

＊ Equivalent measurement equipment may be used.

L

Measuring

frequency

DC resistance

Part No.

Idc1

Idc1

Idc2

(μH)

Tolerance

(MHz)

(

: )max.

(

: )typ.

(A)max.

(A)typ.

(A)typ.

0.47

±30%

1.0

0.056

0.047

2.75

3.10

2.15

VLS252012ET-R47N

1.0

±30%

1.0

0.087

0.073

2.20

2.45

1.70

VLS252012ET-1R0N

1.5

±30%

1.0

0.126

0.105

1.80

2.00

1.45

VLS252012ET-1R5N

2.2

±20%

1.0

0.154

0.129

1.55

1.75

1.30

VLS252012ET-2R2M

3.3

±20%

1.0

0.272

0.227

1.25

1.40

0.98

VLS252012ET-3R3M

4.7

±20%

1.0

0.405

0.338

1.05

1.20

0.81

VLS252012ET-4R7M

6.8

±20%

1.0

0.612

0.510

0.85

0.95

0.65

VLS252012ET-6R8M

10

±20%

1.0

0.756

0.630

0.73

0.82

0.59

VLS252012ET-100M

Measurement item

Product No.

Manufacturer

L

4194A

Agilent Technologies

DC resistance

VP-2941A

Panasonic

Rated current Idc1

4285A+42841A+42842C

Agilent Technologies
