(a)

(c)

(b)

(e)

(d)

1. PART NO. EXPRESSION :

(b) Dimension code

(c) Inductance code : R56 = 0.56uH

(a) Series code

2. CONFIGURATION & DIMENSIONS :

4. MATERIALS :

SUPERWORLD ELECTRONICS (S) PTE LTD

(a) Core : Iron Powder R Core

(c) Wire : Enamelled Copper Wire

3. SCHEMATIC :

(d) Tolerance code : M = ± 20%

(e) F : Lead Free

SDL0806 SERIES

PG. 1

NOTE : Specifications subject to change without notice. Please check our website for latest information.

07.11.2012

(b) Core : Iron Powder RI Core

b) Irms(A) : Will cause temperature rise approximately 40° C without core loss

a) Ambient temp. : 25° C

5. GENERAL SPECIFICATION :

F

E

D

C

B

A

8.2 MAX.

7.0 MAX.

3.5± 0.5

8.2 MAX.

6.3± 0.5

0.7± 0.1

PCB Pattern

b

a

e

c

d

(e) Terminal : Tinned Copper Plate

(d) Adhesive : Epoxy

c) Isat(A) : Will cause L to drop approximately 25%

0

HIGH CURRENT POWER INDUCTORS

Unit:m/m

S D L 0 8 0 6 - R 5 6 M F

A

D

C

E

R56

4.4± 0.5

9.0
