9 / 21 page ![]() Data Sheet ADA8282 Rev. 0 | Page 9 of 21 200 –50 0 50 100 150 0 1000 800 600 400 200 TIME (ns) NO LOAD 5pF 33pF 66pF 100pF Figure 15. Pulse Response at Various Output Capacitive Loads 0 100 200 300 400 500 600 700 800 900 1000 TIME (ns) –1.5 –1.0 –0.5 0 0.5 1.0 1.5 MODE 0 MODE 1 MODE 2 MODE 3 Figure 16. LargeSignal PulseResponsefor VariousLNAandPGA Bias Modes 500 300 320 340 360 380 400 420 440 460 480 –40 –25 10 5 20 35 50 65 80 95 110 125 TEMPERATURE (°C) Figure 17. Short-Circuit Current vs. Temperature Per Channel 30 20 21 22 23 24 25 26 27 28 29 –40 –25 10 5 20 35 50 65 80 95 110 125 TEMPERATURE (°C) GAIN = 18dB GAIN = 24dB GAIN = 30dB GAIN = 36dB Figure 18. Output Slew Rate vs. Temperature 18 24 30 36 GAIN (dB) –3.4 –3.0 –2.6 –2.2 –1.8 –1.4 –1.0 –0.6 –0.2 0.2 0.6 1.0 1.4 1.8 2.2 2.6 3.0 3.4 Figure 19. Maximum and Minimum Differential VOUT vs. Gain 4 –4 –3 –2 –1 0 1 2 3 10 100 1k 10k 100k OUTPUT LOAD RESISTANCE (Ω) TA = –40°C TA = +25°C TA = +85°C Figure 20. Differential Output Voltage Swing vs. Output Load Resistance |
|
|
