JH32240400A

VER: 0.1

- 3 -

Issue date: 2013/08/01

JEWEL HILL ELECTRONIC CO.,LTD.

1. GENERAL DESCRIPTION.

The JH32240400A model is a Color TFT LCD .This main Module has a 3.2 inch diagonally

measured active display area with 240(RGB)×400 resolution. Each pixel is divided into Red,

Green and Blue sub-pixels and dots which are arranged in vertical stripes.

The LCD color is determined with 262,000 colors signal for each pixel.

The JH32240400A has been designed to apply the interface method that enables low

power, high speed, and high contrast.

The JH32240400A is intended to support applications where thin thickness, wide viewing

angle and low power are critical factors and graphic displays are important.

2. GENERAL FEATURES

Item

Display Panel

Remark

Display Mode

Normally White, Transmissive LCD

Viewing Direction

9 O’CLOCK

Input Signals

8/9/16/18 Bits

Outside Dimensions

47.66mm(W)*80.9mm(H)*2.6mm(T)

Effective Area

Active Area

41.76mm(W)×69.6mm(H)

Number of Pixels

240×RGB×400Pixels

Pixel Pitch

0.174mm(H)×0.174mm(W)

Pixel Arrangement

RGB Vertical stripes

Drive IC

HX8352B
