LED2472G

Absolute maximum ratings

2

Absolute maximum ratings

Stressing the device above the ratings listed in the Table 3 may cause permanent damage

to the device. These are stress ratings only and operation of the device at these or any other

conditions above those indicated in the operating sections of this specification is not implied.

Exposure to absolute maximum rating conditions for extended periods may affect device

reliability.

3

Thermal characteristics

Table 3. Absolute maximum ratings

Symbol

Parameter

Value

Unit

Supply voltage

-0.4 to 7

V

Digital inputs voltage

-0.4 to Vdd+0.4

V

OUT

Driver outputs voltage (R<1:8>, G<1:8>, B<1:8>)

20

V

Io

Output current

80

mA

IGND

GND terminal current

1.9

A

ESD

Electrostatic discharge protection HBM human body model

±2

KV

Electrostatic discharge protection MM machine model

±200

V

Table 4. Thermal characteristics

Symbol

Parameter

Value

Unit

Ta

-40 to +85

°C

TJ-OPR

Operative thermal junction temperature range

-40 to +125

Tstg

Storage temperature range

-55 to +150

25.3

°C/W

33

°C/W

1.

This data must be considered in adequate power dissipation conditions. The junction temperature must be maintained

below 150 °C.

2.

In accordance with JEDEC standard 51-7B. The exposed pad should be soldered directly to the PCB to obtain the thermal

benefits.
