ENVIRONMENTAL

CHARACTERISTICS:

Storage temp. range

-65 to +125°C

Vibration resistance

10 to 2000Hz / 40g

Shocks resistance

10000g / 0.3ms / ½ sine

TERMINATIONS AND

PROCESSING:

Reflow soldering

260°C / 10s max

Package

Ceramic 5 x 3.2 x 1.6mm

Lids

Ceramic

Terminations option T3 on request

(not available on G temperature range)

with tinned Ag/Cu/Zn

E/D option 1 on request

Reaction time ˂ 1μs

Pin 1 open → Pin 3 Clock

H →

Clock

L

→

Low

PRODUCT DESCRIPTION AND

ORDERING INFORMATION:

All specifications subject to change without notice.

Frequency «MHz»

3.6864

4

8

10

12

12.8

14.7456

16

20

24

40

48

Other frequencies from 10 kHz up to 100MHz on request

STANDARD FREQUENCIES:

- No power E/D function (pin 1) before Vdd is setting on

- E/D option not available for F ˂ 500 kHz

- E/D option on request (very low consumption in disable mode).

H

˃ 20MHz

blank

≤ 20MHz

W

= Vdd 2.5V

V

= Vdd 3.3V

blank

= Vdd 5V

C

= -55 to 125°C

E

= -55 to 150°C

D

= -55 to 175°C

G

= -55 to 210°C

X

= custom

Frequency

option 1 E/D

enable / disable

option 2

blank Au plasted

T3 = tinned

customer

spec N°

E/D T3 XXX

TAbLE 1: Idd

(Without load)

Frequency

Fz 32 kHz

F=< 10MHz

≤ 20MHz

>20 to

100MHz

W

=Vdd = 2.5V

< 300μA

< 2mA

< 3mA

< 15mA

V

=Vdd = 3.3V

< 1mA

< 4mA

< 5mA

< 20mA

blank =Vdd = 5V

< 2mA

< 6mA

< 7mA

< 30mA
