SPS-43-48H-CP-RDF

DS-5980 Rev 01 2013-08-23

Table 6 – Receiver Specifications (Electrical)

Parameter

Minimum

Typical

Maximum

Unit

Notes

Differential Output Signal Amplitude

400

-

1600

mVpp

Data Output Rise Time

-

-

260

ps

20% to 80%

Data Output Fall Time

-

-

260

ps

20% to 80%

Signal Detect Output HIGH

2.4

-

Vcc

V

Signal Detect Output LOW

0

-

0.8

V

Table 7 – Digital RSSI Timing Specification

Parameter

Minimum

Typical

Maximum

Unit

Notes

25

-

-

ns

300

-

-

ns

-

-

500

us

-

-

+/- 3

dB

a)

RSSI_ACQ input signal rising edge will trigger RSSI sampling, and falling edge will trigger internal digital RSSI information written to I2C.

It is recommended that host shall not trigger RSSI_ACQ input again until RSSI data is valid in I2C from previous RSSI trigger.

b)

RSSI DDM working range is between -12 to -32 dBm. RSSI DDM accuracy is better than +/- 3dB for input power levels between -15 to -32

dBm, the accuracy reduces to +/- 5 dBm for -12 dBm to -15 dBm. If the data pattern is at least 2^7-1 or longer, a minimum average of 8

times is strongly recommended to maintain the RSSI reading accuracy.
