SM5846AP

NIPPON PRECISION CIRCUITS—8

Audio

ICs

SPECIFICATIONS

Absolute Maximum Ratings

VSS = 0 V

Recommended Operating Conditions

VSS = 0 V

DC Electrical Characteristics

VDD = 4.5 to 5.5 V, VSS = 0 V, Ta = −20 to 70 °C

Parameter

Symbol

Rating

Unit

Supply voltage range

VDD

−0.3 to 7.0

Input voltage range

VIN

− 0.3 to V

DD + 0.3

Storage temperature range

Tstg

−40 to 125

°C

Power dissipation

750

Soldering temperature

Tsld

255

°C

Soldering time

tsld

Parameter

Symbol

Rating

Unit

Supply voltage range

VDD

4.5 to 5.5

Operating temperature range

Topr

−20 to 70

°C

Parameter

Symbol

Condition

Rating

Unit

min

typ

max

Supply current consumption1

1. VDD = 5.0 V, fsys = 18.432 MHz, 384fs operation, no output load.

IDD

–

110

130

HIGH-level input voltage

VIH

All inputs

0.7VDD

––

LOW-level input voltage

VIL

All inputs

–

0.3VDD

XTI AC-coupled input voltage

VINAC

0.3VDD

––

Vp-p

HIGH-level output voltage

VOH

All outputs, IOH = −1 mA

VDD − 0.4

–

LOW-level output voltage

VOL

All outputs, IOL = 2 mA

–

0.4

XTI HIGH-level input current

IIH

VIN = VDD

–10

µA

XTI LOW-level input current

IIL

VIN = VSS

–10

µA

LOW-level input current

IIL

Inputs excluding XTI,

VIN = VSS

–10

µA

Input leakage current

ILH

Inputs excluding XTI,

VIN = DVDD

–

1.0

µA
