UNISONIC TECHNOLOGIES CO., LTD

SB260

DIODE

www.unisonic.com.tw

1 of 3

QW-R601-240.C

2.0A SCHOTTKY BARRIER

RECTIFIER



DESCRIPTION

The UTC SB260 is a 2.0A schottky barrier rectifier, it uses

UTC’s advanced technology to provide customers with low forward

voltage drop, high current capability and high efficiency, etc.

The UTC SB260 is suitable for use in free wheeling, high

frequency

inverters,

low

voltage

and

polarity

protection

applications.



FEATURES

* Low forward voltage drop

* High current capability

* High surge capability

* Low power loss

* High efficiency

DO-41

SMA

(JEDEC DO-214AC)

+

-



ORDERING INFORMATION

Ordering Number

Pin Assignment

Lead Free

Halogen Free

Package

1

2

Packing

SB260L-SMA-R

SB260G-SMA-R

SMA

K

A

Tape Reel

SB260L-Z41-B

SB260G-Z41-B

DO-41

K

A

Tape Box

SB260L-Z41-R

SB260G-Z41-R

DO-41

K

A

Tape Reel

Note: Pin Assignment: A: Anode

K: Cathode

(1) B: Tape Box, R: Tape Reel

(2) SMA: SMA, Z41: DO-41

(3) L: Lead Free, G: Halogen Free and Lead Free

SB260L-SMA-R

(1)Packing Type

(2)Package Type

(3)Green Package



MARKING

SMA

DO-41

Date Code

Cathode Band for

uni-directional Only

UTC

SB260

L: Lead Free

G: Halogen Free

SB260

Date Code

L: Lead Free

G: Halogen Free

Cathode Band for uni-directional Only
