FR107G

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 4

www.unisonic.com.tw

QW-R601-251.B

ABSOLUTE MAXIMUM RATINGS

Ratings at 25°C ambient temperature unless otherwise specified.

Single phase half-wave 60Hz, resistive or inductive load, for capacitive load current derate by 20%.

PARAMETER

SYMBOL

RATINGS

UNIT

Working Peak Reverse Voltage

1000

V

Repetitive Peak Reverse Voltage

1000

V

Maximum RMS Reverse Voltage

700

V

DC Blocking Voltage

1000

V

1.0

A

Peak Forward Surge Current 8.3ms Single Half

Sine-Wave Superimposed on Rated Load

30

A

Junction Temperature

-55~+150

°C

Storage Temperature

-55~+150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient (Note 3)

50

°C/W

ELECTRICAL CHARACTERISTICS

Ratings at 25°C ambient temperature unless otherwise specified.

Single phase half-wave 60Hz, resistive or inductive load, for capacitive load current derate by 20%.

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Instantaneous Forward Voltage

1.3

V

DC Reverse Current at Rated DC Blocking

Voltage

5.0

μA

50.0

μA

Reverse Recovery Time (Note 1)

500

ns

Junction Capacitance (Note 2)

15.0

pF

2. Measured at 1MHz and applied reverse voltage of 4.0V D.C.

3. Thermal resistance from junction to ambient at 0.375” (9.5mm) lead length, P.C.B. mounted.
