ES2J

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 4

www.unisonic.com.tw

QW-R601-268.A

ABSOLUTE MAXIMUM RATINGS

Ratings at 25°C ambient temperature unless otherwise specified.

Single phase half-wave 60Hz, resistive or inductive load, for capacitive load current derate by 20%.

PARAMETER

SYMBOL

RATINGS

UNIT

Working Peak Reverse Voltage

600

V

Repetitive Peak Reverse Voltage

600

V

Maximum RMS Reverse Voltage

420

V

DC Blocking Voltage

600

V

2.0

A

Peak Forward Surge Current 8.3ms Single Half

Sine-Wave Superimposed on Rated Load

50

A

Junction Temperature

-55~+150

°C

Storage Temperature

-55~+150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient (Note 3)

40

°C/W

ELECTRICAL CHARACTERISTICS

Ratings at 25°C ambient temperature unless otherwise specified.

Single phase half-wave 60Hz, resistive or inductive load, for capacitive load current derate by 20%.

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP MAX UNIT

Instantaneous Forward Voltage

1.7

V

DC Reverse Current at Rated DC Blocking

Voltage

5

μA

50

μA

Reverse Recovery Time (Note 1)

35

ns

Junction Capacitance (Note 2)

60

pF

2. Measured at 1MHz and applied reverse voltage of 4.0V D.C.

3. P.C.B. mounted with 0.2×0.2” (5.0×5.0mm) copper pad areas.
