UNISONIC TECHNOLOGIES CO., LTD

MBR840

Preliminary

DIODE

www.unisonic.com.tw

1 of 3

QW-R202-053.a

8A SCHOTTKY BARRIER

RECTIFIER



DESCRIPTION

The UTC MBR840 is a 8A schottky barrier rectifier, it uses

UTC’s advanced technology to provide the customers with high

surge capability, high efficiency, high current capability, low power

loss and low forward voltage drop, etc.

The UTC MBR840 is suitable for free wheeling and polarity

protection, etc.

 FEATURES

* Low Reverse Current

* Low Stored Charge, Majority Carrier Conduction

* Low Power Loss/High Efficiency

* Highly Stable Oxide Passivated Junction



SYMBOL

SMB

(JEDEC DO-214AA)

+

-



ORDERING INFORMATION

Ordering Number

Pin Assignment

Lead Free

Halogen Free

Package

1

2

Packing

MBR840L-SMB-R

MBR840G-SMB-R

SMB

K

A

Tape Reel

Note: Pin Assignment: A: Anode

K: Cathode



MARKING

Date Code

Cathode Band for

uni-directional Only

UTC

MBR840

L: Lead Free

G: Halogen Free
