MB6FU

SCHOTTKY BRIDGE

UNISONICTECHNOLOGIESCO.,LTD

2 of 4

www.unisonic.com.tw

QW-R202-039.A



ABSOLUTE MAXIMUM RATINGS (TA=25°C, unless otherwise noted)

Single phase, half wave, 60Hz, resistive or inductive load.

For capacitance load,derate current by 20%.

PARAMETER

SYMBOL

RATINGS

UNIT

DC Blocking Voltage

VDC

600

RMS Voltage

VRMS

420

Repetitive Peak Reverse Voltage

VRRM

600

Average Forward Rectified Current

TA=40°C (Note 2)

1.0

Peak Forward Surge Current, 8.3ms Single Half Sine-Wave

Superimposed on Rated Load

IFSM

Operating Junction Temperature Range

-55~+125

°C

Storage Temperature Range

TSTG

-55~+150

°C

Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. Mounted on glass epoxy pc board with 1.3mm

2 solder pad.



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

θJA

°С/W

Note: Measured at 1.0 MHz and applied reverse voltage of 4.0V D.C.



ELECTRICAL CHARACTERISTICS (TA=25°C unless otherwise noted)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Instantaneous Forward Voltage

IF=1.0A

1.1

TJ=25°C

5.0

μA

DC Reverse Current at Rated DC Blocking

Voltage

TJ=125°C

500

μA
