ES3J

DIODE

UNISONICTECHNOLOGIESCO.,LTD

3 of 3

www.unisonic.com.tw

QW-R202-035.A



TYPICAL CHARACTERISTICS

Forward Current Derating Curve

3.0

2.0

1.5

1.0

0

0

25

50

75

100 125 150

175

Single Phase

Half Wave

Resistive or

inductive Load

Ambient Temperature (°C)

Maximum Non-Repetitive Peak Forward Surge Current

150

120

90

60

30

0

1

10

100

Number of Cycles aT 60Hz

8.3ms Single

Half Sine-Wave

(JEDEC Method)

0.5

2.5

Typical Instantaneous Forward Characteristics

100

10

1

0.1

0.6

0.8

1.2

1.4

1.8

2.0

Instantaneous Forward Voltage (V)

Pulse Width=300s

1% Duty Cycle

1.6

1.0

Typical Junction Capacitance

100

10

1

10

100

Reverse Voltage (V)
