ER1004

Preliminary

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R201-099.a



ABSOLUTE MAXIMUM RATINGS

Ratings at 25°C ambient temperature unless otherwise specified. Single phase, half wave, 60Hz, resistive or

inductive load. For capacitance load, derate current by 20%.

PARAMETER

SYMBOL

RATINGS

UNIT

Recurrent Peak Reverse Voltage

400

V

RMS Voltage

280

V

10

A

Peak Forward Surge Current 8.3ms Single Half Sine-Wave

Superimposed on Rated Load (JEDEC Method)

150

A

Operating Junction Temperature

-55~+150

°C

Storage Temperature

-55~+150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



THERMAL CHARACTERISTICS (PER LEG)

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

62.5

°C/W

Junction to Case

5

°C/W



ELECTRICAL CHARACTERISTICS

Ratings at 25°C ambient temperature unless otherwise specified. Single phase, half wave, 60Hz, resistive or

inductive load. For capacitance load, derate current by 20%

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Forward Voltage Drop

1.3

V

10

μA

DC Reverse Current at Rated DC Blocking

Voltage

500

μA

Reverse Recovery Time (Note 2)

50

ns

Junction Capacitance (Note 1)

62

pF

Notes: 1. Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
