BAS85

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R202-015.B



ABSOLUTE MAXIMUM RATINGS

PARAMETER

SYMBOL

RATINGS

UNIT

Continuous Reverse Voltage

30

V

200

mA

300

mA

Non-Repetitive Peak Forward Current

5

A

200

mW

Junction Temperature

125

°C

Operating Ambient Temperature

-55~+125

°C

Storage Temperature

-55~+150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient (Note 1)

430

°C/W



ELECTRICAL CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Reverse Breakdown Voltage

30

V

Forward Voltage (Note 2)

0.24

V

0.32

V

0.4

V

0.5

V

0.8

V

Leakage Current

2.0

μA

Reverse Recovery Time

5

ns

Junction Capacitance

10

pF

Notes: 1. Valid provided that leads at a distance of 4mm from case are kept at ambient temperature
