UT40N03T
Power MOSFET
UNISONICTECHNOLOGIESCO.,LTD
3 of 5
www.unisonic.com.tw
QW-R502-172.G
ELECTRICAL CHARACTERISTICS (TJ =25°C, unless otherwise specified)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN TYP MAX UNIT
OFF CHARACTERISTICS
Drain-Source Breakdown Voltage
BVDSS
VGS =0 V, ID =250µA
30
V
Drain-Source Leakage Current
IDSS
VDS=30V,VGS =0V,TJ =25°C
1
µA
Gate-Source Leakage Current
IGSS
VGS = ±25 V
±100
nA
Breakdown Voltage Temperature Coefficient ∆BVDSS/∆TJ Reference to 25°C, ID=1mA
0.032
V/°C
ON CHARACTERISTICS
Gate-Threshold Voltage
VGS(TH)
VDS =VGS, ID =250 µA
1
3
V
Drain-Source On-State Resistance
RDS(ON)
VGS =10 V, ID =18 A
25
mΩ
VGS =4.5 V, ID =14 A
45
DYNAMIC PARAMETERS
Input Capacitance
CISS
VDS=25V, VGS =0V,
f=1.0MHz
655
pF
Output Capacitance
COSS
145
Reverse Transfer Capacitance
CRSS
95
SWITCHING PARAMETERS
Turn-ON Delay Time
tD(ON)
VGS=10V,VDS=15V,
RD=0.83Ω, ID =18 A,
RG =3.3 Ω
6
ns
Turn-ON Rise Time
tR
62
Turn-OFF Delay Time
tD(OFF)
16
Turn-OFF Fall-Time
tF
4.4
Total Gate Charge
QG
VDS =20V, VGS =4.5V,
ID =18A
8.8
nC
Gate-Source Charge
QGS
2.5
Gate-Drain Charge
QGD
5.8
SOURCE-DRAIN DIODE RATINGS AND CHARACTERISTICS
Drain-Source Diode Forward Voltage
VSD
IS=28 A, VGS=0V
1.3
V
Maximum Continuous Drain-Source Diode
Forward Current
IS
VD=VG=0V , VS=1.3V
28
A
Maximum Pulsed Drain-Source Diode
Forward Current
ISM
95
A
Notes: 1. Pulse width limited by TJ(MAX).
Notes: 2. Pulse width ≤ 300us, duty cycle ≤ 2%.
