2 / 3 page

UB2K

DUAL TRANSISTOR

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R218-006.B



ABSOLUTE MAXIMUM RATING (TA=25°C, unless otherwise specified)

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VCC

-50

Input Voltage

VIN

-40

+10

Output Current

IOUT

-30

-100

Power Dissipation

+150

Junction Temperature

+150

°C

Storage Temperature

TSTG

-55 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



ELECTRICAL CHARACTERISTICS (TA=25°C, unless otherwise specified)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Input Voltage

VI(OFF)

VCC=-5V, IOUT=-100µA

-0.5

VI(ON)

VOUT=-0.3V, IOUT=-2mA

-3

Output Voltage

VO(ON)

IO/II=-10mA/-0.5mA

-0.1

-0.3

Input Current

IIN

VIN=-5V

-0.18 mA

Output Current

IO(OFF)

VCC=-50V, VIN=0V

-0.5

µA

DC Current Gain

hFE

VOUT=-5V, IOUT=-5mA

Transition Frequency

VCE=-10V, IE=5mA, f=100MHZ (Note)

250

MHz

Input Resistance

32.9

61.1

kΩ

Resistance Ratio

R2/R1

0.8

1.2

Note: Transition frequency of the device
