background image
2SC3468
NPN EPITAXIAL SILICON TRANSISTOR
UNISONICTECHNOLOGIESCO.,LTD
2 of 5
www.unisonic.com.tw
QW-R208-037.B
ABSOLUTE MAXIMUM RATING (TA=25°C, unless otherwise specified)
PARAMETER
SYMBOL
RATINGS
UNIT
Collector-to-Base Voltage
VCBO
300
V
Collector-to-Emitter Voltage
VCEO
300
V
Emitter-to-Base Voltage
VEBO
5
V
Collector Current
IC
100
mA
Collector Current (Pulse)
ICP
200
mA
Collector Dissipation
PC
1.0
W
Junction Temperature
TJ
0 ~ +125
°C
Storage Temperature
TSTG
-65 ~ +125
°C
Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
2. The device is guaranteed to meet performance specification within 0
°C ~70°C operating temperature
range and assured by design from –20
°C ~85°C.
ELECTRICAL CHARACTERISTICS (TA=25°C, unless otherwise specified)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Collector Cutoff Current
ICBO
VCB = 200V, IE = 0
0.1
µA
Emitter Cutoff Current
IEBO
VEB = 4V, IC = 0
0.1
µA
DC Current Gain
hFE
VCE = 10V, IC = 10mA
40
320
Gain-Bandwidth Product
fT
VCE = 30V, IC = 10mA
150
MHz
Collector-to-Emitter Saturation Voltage
VCE (sat)
IC = 20mA, IB = 2mA
0.6
V
Base-to-Emitter Saturation Voltage
VBE (sat)
IC = 20mA, IB = 2mA
1.0
V
Collector-to-Base Breakdown Voltage
V(BR) CBO
IC = 10µA, IE = 0
300
V
Collector-to-Emitter Breakdown Voltage
V(BR) CEO
IC = 1mA, RBE = ∞
300
V
Emitter-to-Base Breakdown Voltage
V(BR) EBO
IE = 10µA, IC = 0
5
V
Output Capacitance
Cob
VCB = 30V, f = 1MHz
2.6
pF
Reverse Transfer Capacitance
Cre
VCB = 30V, f = 1MHz
1.8
pF
CLASSIFICATION of hFE
RANK
C
D
E
F
RANGE
40 ~ 80
60 ~ 120
100 ~ 200
160 ~ 320
