U74LVC2G08

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

3 of 5

www.unisonic.com.tw

QW-R502-437.D



ABSOLUTE MAXIMUM RATING (Note)

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VCC

-0.5~6.5

Input Voltage

VIN

-0.5~6.5

Output Voltage (Active Mode)

VOUT

-0.5~VCC+0.5

Output Voltage (Power-Down Mode)

VOUT

-0.5~+6.5

Input Clamp Current

IIK

-50

Output Clamp Current

IOK

±50

Output Current

IOUT

±50

VCC or GND Current

ICC

±100

Power Dissipation

PTOT

300

Storage Temperature

TSTG

-65 ~ +150

°C

Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. The input and output voltage ratings may be exceeded if the input and output current ratings are observed.



RECOMMENDED OPERATING CONDITIONS

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX UNIT

Supply Voltage

VCC

Operating

1.65

5.5

Input Voltage

VIN

5.5

Output Voltage

VOUT

Active Mode

VCC

Power-Down Mode; VCC = 0V;

5.5

Input Transition Rise or Fall Rate

tR / tF

VCC=1.65V to 2.7V

ns/V

VCC=2.7V to 5.5V

Operating Temperature

TOPR

-40

125

°C



ELECTRICAL CHARACTERISTICS (TA = 25°C, unless otherwise specified)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

High-Level Input Voltage

VIH

VCC = 1.65V to 1.95V

0.65×VCC

VCC = 2.3V to 2.7V

1.7

VCC = 2.7V to 3.6V

2.0

VCC = 4.5V to 5.5V

0.7×VCC

Low-Level Input Voltage

VIL

VCC = 1.65V to 1.95V

0.35×VCC

VCC = 2.3V to 2.7V

0.7

VCC = 2.7V to 3.6V

0.8

VCC = 4.5V to 5.5V

0.3×VCC

High-Level Output Voltage

VOH

IOH = -100μAVCC = 1.65V to 5.5V VCC -0.1

IOH = -4mA

VCC = 1.65V

1.2

1.53

IOH = -8mA

VCC = 2.3V

1.9

2.13

IOH = -12mA VCC = 2.7V

2.2

2.50

IOH = -24mA VCC = 3V

2.3

2.60

IOH = -32mA VCC = 4.5V

3.8

4.10

Low-Level Output Voltage

VOL

IOL = 100μAVCC = 1.65V to 5.5V

0.1

IOL = 4mA

VCC = 1.65V

0.08

0.45

IOL = 8mA

VCC = 2.3V

0.14

0.3

IOL = 12mA

VCC = 2.7V

0.19

0.4

IOL = 24mA

VCC = 3.0V

0.37

0.55

IOL = 32mA

VCC = 4.5V

0.43

0.55

Input Leakage Current

II(LEAK)

VIN = 5.5V or GND, VCC = 5.5V

±0.1

±5

μA

OFF-state Current

IOFF

VIN or VO = 5.5V, VCC = 0V

±0.1

±10

μA

Quiescent Supply Current

VIN = VCC or GND, IOUT= 0, VCC= 5.5V

0.1

μA

Additional quiescent Supply

Current

 IQ

One input at VCC – 0.6V; other inputs

at VCC or GND; VCC=2.3V to 5.5V

500

μA

Input Capacitance

CIN

2.5
