U74CBT3253

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

5 of 5

www.unisonic.com.tw

QW-R502-948.B



TEST CIRCUIT AND WAVEFORMS

TEST

V∆

4V

≤2.5ns

Open

50pF

500Ω

5V±0.5V

≤2.5ns

Open

50pF

500Ω

4V

GND

≤2.5ns

0.3V

7V

50pF

500Ω

5V±0.5V

GND

≤2.5ns

0.3V

7V

50pF

500Ω

4V

≤2.5ns

0.3V

Open

50pF

500Ω

5V±0.5V

≤2.5ns

0.3V

Open

50pF

500Ω

PROPAGATION DELAY TIMES

ENABLE AND DISABLE TIMES

2. All input pulses are supplied by generators having the following characteristics: PRR≤10MHz,

3. The outputs are measured one at a time with one transition per measurement.

7. All parameters and waveforms are not applicable to all devices.
