UCD4014B

Preliminary

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

4 of 8

www.unisonic.com.tw

QW-R502-606.c

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

-0.5 ~ 20

V

Input Voltage

V

Output Voltage

V

±10

mA

Power Dissipation

500

mW

200

mW

Storage Temperature

-65 ~ +150

°C

Note: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. The input and output voltage ratings may be exceeded if the input and output current ratings are observed.

RECOMMENDED OPERATING COMDITIONS

PARAMETER

SYMBOL

CONDITIONS

MIN

MAX

UNIT

Supply Voltage

3

18

V

Clock Pulse Width

180

-

ns

80

-

50

-

Clock Frequency

-

3

MHz

-

6

-

8.5

Clock Rise and Fall Time

-

15

μs

-

15

-

15

Set-up Time, Serial Input

120

-

ns

80

-

60

-

Set-up Time, Parallel Input

80

-

ns

50

-

40

-

Set-up Time, Parallel/Serial Control

180

-

ns

80

-

60

-

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP MAX UNIT

Quiescent Supply Current

0.04

5

μA

0.04

10

0.04

20

0.08

100

Output Low (Sink) Current

0.51

1

mA

1.3

2.6

3.4

6.8

Output High (Source) Current

-0.51

-1

mA

-1.6

-3.2

-1.3

-2.6

-3.4

-6.8

Output Voltage: Low-Level

0

0.05

V

0

0.05

0

0.05
