U74ACT14
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
3 of 4
www.unisonic.com.tw
QW-R502-195.B
ABSOLUTE MAXIMUM RATINGS (unless otherwise specified)
PARAMETER
SYMBOL
RATINGS
UNIT
Supply Voltage
VCC
-0.5~7
V
Input Voltage
VIN
-0.5~ VCC+0.5
V
Output Voltage
VOUT
-0.5~VCC+0.5
V
Input Clamp Current
IIK
±20
mA
Output Clamp Current
IOK
±20
mA
Output Current
IOUT
±50
mA
VCC or GND Current
ICC
±50
mA
Storage Temperature
TSTG
-65 ~ +150
°C
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
RECOMMENDED OPERATING CONDITIONS
PARAMETER
SYMBOL
MIN
TYP
MAX
UNIT
Supply Voltage
VCC
4.5
5.5
V
Input Voltage
VIN
0
VCC
V
Output Voltage
VOUT
0
VCC
V
Operating Temperature
TA
-40
+85
°C
ELECTRICAL CHARACTERISTICS
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
High-Level Input Voltage
VIH
VCC=4.5V
2.0
V
VCC=5.5V
2.0
V
Low-Level Input Voltage
VIL
VCC=4.5V
0.8
V
VCC=5.5V
0.8
V
Hysteresis
VTH
VCC=4.5V
0.4
1.4
V
VCC=5.5V
0.5
1.6
V
High-Level Output Voltage
VOH
VCC=4.5V, IOH=-50μA
4.34
4.49
V
VCC=5.5V, IOH=-50μA
5.4
5.49
V
VCC=4.5V, IOH=-24mA
3.86
V
VCC=5.5V, IOH=-24mA
4.86
V
Low-Level Output Voltage
VOL
VCC=4.5V, IOL=50μA
0.001
0.1
V
VCC=5.5V, IOL=50μA
0.001
0.1
V
VCC=4.5V, IOL=24mA
0.36
V
VCC=5.5V, IOL=24mA
0.36
V
Input Leakage Current
II(LEAK)
VCC=5.5V, VIN=5.5V or GND
±0.1
μA
Maximum Icc/Input
ICCT
VCC=5.5V, VIN=VCC-2.1V
0.6
mA
Quiescent Supply Current
IQ
VCC=5.5V, VIN=VCC or GND, IOUT=0
2.0
μA
Input Capacitance
CIN
VCC=OPEN
4.5
pF
Note: Not more than one output should be tested at a time, and the duration of the test should not exceed 2 ms.
SWITCHING CHARACTERISTICS
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Propagation delay from input
(A) to output(Y)
tPLH
VCC=5.0V±0.5V, CL=50pF
3.0
8.0
10.0
ns
tPHL
VCC=5.0V±0.5V, CL=50pF
3.0
8.0
10.0
ns
OPERATING CHARACTERISTIC
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Power Dissipation Capacitance
Cpd
VCC=5
80
pF
