ABSOLUTE MAXIMUM RATINGS (Ta=25°C)

PARAMETER

SYMBOL

RATING

UNIT

Supply Voltage (Note 2)

VCC

±18

Input Voltage (Note 3)

VIN

±15

Differential Input Voltage (Note 4)

VI(DIFF)

±30

Power Dissipation

680

Output Short-Circuit Duration (Note 5)

Infinite

Operating Temperature

TOPR

0 ~ +70

°C

Storage Temperature

TSTG

-65 ~ +150

°C

Notes: 1.

Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

All voltage values, except differential voltage, are with respect to the zero reference level (ground) of the

supply voltages where the zero reference level is the midpoint between VCC- and VCC+.

The magnitude of the input voltage must never exceed the magnitude of the supply voltage or 15 volts,

whichever is less.

Differential voltages are at the non-inverting input terminal with respect to the inverting input terminal.

The output may be shorted to ground or to either supply. Temperature and/or supply voltages must be

limited to ensure that the dissipation rating is not exceeded.

ELECTRICAL CHARACTERISTICS (VCC=±15V, Ta=25°C, unless otherwise specified)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Input Offset Voltage

VI(OFF)

RS≦10kΩ, VCM=0V

Temperature Coefficient of Input

Offset Voltage

ΔVI(OFF)

RS=50Ω

μV/

°C

Input Offset Current (Note)

II(OFF)

VCM=0V

200

Input Bias Current (Note1)

II(BIAS)

VCM=0V

400

Input Common Mode Voltage

VI(CM)

±10

-12~+15

Output Voltage Swing

VO(SW)

RL=10kΩ

Large Signal Voltage Gain

RL≧2kΩ, VOUT=±10V

150

V/mV

Gain Bandwidth Product

GBW

MHz

Input Resistance

RIN

Ω

Common Mode Rejection Ratio

CMR

RS≦10kΩ

100

Supply Voltage Rejection Ratio

SVR

RS≦10kΩ

100

Supply Current

ICC

No Load

1.4

2.8

Channel Separation

V01/V02

GV=100

120

Slew Rate

VIN=10V, RL=2kΩ, CL=100pF,

unity gain

2.0

V/μs

Rise Time

0.1

μs

Overshoot Factor

KOV

VIN=20mV, RL=2kΩ, CL=100pF,

unity gain

Equivalent Input Noise Voltage

RS=100Ω, f=1KHz

Note: The Input bias currents are junction leakage currents, which approximately double for every 10

°C increase in

the junction temperature.
