A7623

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

3 of 6

www.unisonic.com.tw

QW-R121-014,A

ABSOLUTE MAXIMUM RATINGS (Ta = 25 )

℃

PARAMETER

SYMBOL

RATINGS

UNIT

Power Supply Voltage

VCC

8.0

Power Dissipation

550

Derating Rate at Ta=25

°C

5.5

°C/mW

Operating Temperature

TOPR

-25 ~ +75

°C

Storage Temperature

TSTG

-55 ~ +125

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

ELECTRICAL CHARACTERISTICS

(Ta = 25°C , VCC = 5V, VIN DC=2.1V and load is two system drive)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Operating Voltage

VCC

4.5

5.0

5.5

Supply Current

ICC

No signal

25.2

37.8

Voltage Gain

f = 1MHz, sine wave ,VIN = 2.0VP-P

-1.0

-0.5

Maximum Output Level

VO(MAX) f = 1kHz, sine wave, THD = 1.0%

2.9

3.4

VP-P

Frequency Characteristic

10MHz / 1MHz, sine wave ,VIN = 1.0VP-P

-3

Inter Channel Crosstalk

f = 4.43MHz, sine wave ,VIN = 2.0VP-P

-60

Total Harmonic Distortion

THD

f = 1kHz, sine wave, VIN = 1.0VP-P

0.1

0.5

Differential Gain 75Ω Drive 1

DG1

0.4

1.0

Differential Phase 75Ω Drive 1

DP1

0.4

1.0

deg

Differential Gain 75Ω Drive 2

DG2

0.7

2.0

Differential Phase 75Ω Drive 2

DP2

VIN = 2.0VP-P, standard staircase signal

0.7

2.0

Deg
