M2125

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

3 of 5

www.unisonic.com.tw

QW-R105-025.G



ABSOLUTE MAXIMUM RATINGS (TA=25°C, unless otherwise specified)

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

+20

Differential Input Voltage

VI(DIFF)

+20

Input Voltage (Note 2)

VIN

-0.3 ~ +20

Power Dissipation (TC=25°C)

SOT-25

200

SOT-353

110

Junction Temperature

+125

°C

Operating Temperature

TOPR

-40~ +85

°C

Storage Temperature

TSTG

-40~+125

°C

Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. When the supply voltage is less than +20V, the absolute maximum input voltage is equal to the supply

voltage.



THARMAL DATA (TJ=150°C, TA=25°C, unless otherwise specified)

PARAMETER

SYMBOL

RATING

UNIT

junction to Ambient

SOT-25

θJA

230

°C/W

SOT-353

350

°C/W



ELECTRICAL CHARACTERISTICS(V+=5V, TA=25°C)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX UNIT

Input Offset Voltage

VI(OFF)

RS=0Ω

Input Offset Current

II(OFF)

Input Bias Current

II(BIAS)

250

Large Signal Voltage Gain

RL≥2kΩ

100

Maximum Output Voltage Swings

VOM

RL=2kΩ

3.5

Input Common Mode Voltage

VI(CM)

3.5

Common Mode Rejection Ratio

Supply Voltage Rejection Ratio

SVR

Output Source Current

ISOURCE

VIN

+=1V, VIN-=0V

Output Sink Current

ISINK

VIN

+=0V, VIN-=1V

Operating Current

ICC

RL=∞

1.0

1.75

Slew Rate

1.2

V/μs

Unity Gain Frequency

1.2

MHz
