UNISONIC TECHNOLOGIES CO., LTD

TL494

LINEAR INTEGRATED CIRCUIT

www.unisonic.com.tw

1 of 8

Copyright © 2015 Unisonic Technologies Co., Ltd

QW-R103-004. J

VOLTAGE MODE PWM

CONTROL CIRCUIT



DESCRIPTION

The UTC TL494 incorporates all the functions required in the

construction of a pulse-width modulation switching circuit.

Designed primarily for switching power supply control or DC-DC

convectors, it offers the systems engineer the flexibility to tailor

control circuitry to its own application.



FEATURES

* Complete PWM power control circuitry

* Uncommitted outputs for 200mA sink or source current

* Output control selects single ended or push pull operation

* Internal circuitry prohibits double pulses over total range

* Easy synchronization



ORDERING INFORMATION

Ordering Number

Lead Free

Halogen Free

Package

Packing

TL494L-D16-T

TL494G-D16-T

DIP-16

Tube

-

TL494G-S16-R

SOP-16

Tape Reel

-

TL494G-P16-R

TSSOP-16

Tape Reel



MARKING

DIP-16

SOP-16 / TSSOP-16
