IRF1405Z/S/LPbF

12

www.irf.com

Data and specifications subject to change without notice.

This product has been designed and qualified for the Industrial market.

Qualification Standards can be found on IR’s Web site.

IR WORLD HEADQUARTERS: 233 Kansas St., El Segundo, California 90245, USA Tel: (310) 252-7105

TAC Fax: (310) 252-7903

Visit us at www.irf.com for sales contact information. 07/2010

TO-220AB packages are not recommended for Surface Mount Application.

Dimensions are shown in millimeters (inches)

3

4

4

TRR

FEED DIRECTION

1.85 (.073)

1.65 (.065)

1.60 (.063)

1.50 (.059)

4.10 (.161)

3.90 (.153)

TRL

FEED DIRECTION

10.90 (.429)

10.70 (.421)

16.10 (.634)

15.90 (.626)

1.75 (.069)

1.25 (.049)

11.60 (.457)

11.40 (.449)

15.42 (.609)

15.22 (.601)

4.72 (.136)

4.52 (.178)

24.30 (.957)

23.90 (.941)

0.368 (.0145)

0.342 (.0135)

1.60 (.063)

1.50 (.059)

13.50 (.532)

12.80 (.504)

330.00

(14.173)

MAX.

27.40 (1.079)

23.90 (.941)

60.00 (2.362)

MIN.

30.40 (1.197)

MAX.

26.40 (1.039)

24.40 (.961)

NOTES :

1. COMFORMS TO EIA-418.

2. CONTROLLING DIMENSION: MILLIMETER.

3. DIMENSION MEASURED @ HUB.

4. INCLUDES FLANGE DISTORTION @ OUTER EDGE.
