NJG1555KB2

- 3 -

nTERMINAL INFORMATION

PIN No. SYMBOL

DESCRIPTIONS

1

LOIN

Local power input terminal of local amplifier.

External matching circuit is required.

2

GND

Ground terminal (0V).

3

RFIN

RF input terminal of mixer. External matching circuit is required.

4

IFOUT

IF signal output terminal for mixer external matching circuit is required.

Please connect mixer power supply through choke inductor (L6) as shown in

test circuit.

5

BPC

Optional bypass capacitor terminal for mixer.

Please connect optimum capacitor if need for tuning Gc or IP3.

6

VLO

Local amplifier supply terminal.

Please place R1 & L4 close to this terminal as shown in test circuit.

NOTE:

1) Ground terminal (2pin) should be connected with ground plane by multiple via holes

for good grounding.
