NJG1515AVB2

- 4 -

nELECTRICAL CHARACTERISTICS 3 [800MHz Rx Mode]

Common Conditions:

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

Frequency range 2

fin2

810

-

885

MHz

RX-ANT1 Insertion Loss

LOSS3

-

0.65

0.80

dB

RX-ANT2 Insertion Loss

LOSS4

-

0.60

0.75

dB

RX-EXT1 Insertion Loss

LOSS5

-

0.70

0.85

dB

RX-EXT2 Insertion Loss

LOSS6

-

0.65

.80

dB

RX-ANT1 Isolation

ISL6

RX-EXT1, RX-EXT2 passing

21

24

-

dB

RX-ANT2 Isolation

ISL7

RX-EXT1, RX-EXT2 passing

22

25

-

dB

RX-EXT1 Isolation

ISL8

RX-ANT2, RX-EXT2 passing

22

25

-

dB

RX-EXT2 Isolation

ISL9

RX-ANT2, RX-EXT1 passing

20

23

-

dB

Pin at 1dB

compression point 1

RX-ANT1, RX-ANT2,

RX-EXT1, RX-EXT2 passing

20

26

-

dBm

VSWR 2

VSWR2

RX-ANT1, RX-ANT2,

RX-EXT1, RX-EXT2 passing

-

1.4

1.6

Switching time 2

TD2

CTL1~3

-

120

500

nsec

Tested on PCB circuit as shown below

Insertion loss of each connectors, striplines, and capacitors are excluded.

TX, RX, ANT1, ANT2, EXT1 and EXT2 are terminated to 50

Ω.

TER1 and TER2 are connected to GND through 5pFcapacitor.
