29.04.2015

APG2C1-365-r4

3 / 4

Radiation Pattern (lambertian lens without optics)

Relative Intensity vs. Angular Displacement

Accessories

Reflectors

CLP17CR, 6° metalized polycarbonate reflector

CLP23CR, 20° metalized polycarbonate reflector

Static Electricity

LEDs are very sensitive to static Electricity and surge voltage. It is recommended to wear a wristband or

an anti-electrostatic glove whenever handling the LEDs

All devices, equipment, and machinery that is used when handling the LEDs must be grounded

properly.

Heat Generation

It is advised to operate these LEDs at a reasonable low temperature for long lifetime and stability. High

operating temperature will result in premature degradation and shortened lifetime.
