11

LTC1663

MS8 Package

8-Lead Plastic MSOP

(LTC DWG # 05-08-1660)

S5 Package

5-Lead Plastic SOT-23

(LTC DWG # 05-08-1633)

MSOP (MS8) 1098

* DIMENSION DOES NOT INCLUDE MOLD FLASH, PROTRUSIONS OR GATE BURRS. MOLD FLASH,

PROTRUSIONS OR GATE BURRS SHALL NOT EXCEED 0.006" (0.152mm) PER SIDE

** DIMENSION DOES NOT INCLUDE INTERLEAD FLASH OR PROTRUSIONS.

INTERLEAD FLASH OR PROTRUSIONS SHALL NOT EXCEED 0.006" (0.152mm) PER SIDE

0.021

± 0.006

(0.53

± 0.015)

0

° – 6° TYP

SEATING

PLANE

0.007

(0.18)

0.040

± 0.006

(1.02

± 0.15)

0.012

(0.30)

REF

0.006

± 0.004

(0.15

± 0.102)

0.034

± 0.004

(0.86

± 0.102)

0.0256

(0.65)

BSC

12

3

4

0.193

± 0.006

(4.90

± 0.15)

8

7 6

5

0.118

± 0.004*

(3.00

± 0.102)

0.118

± 0.004**

(3.00

± 0.102)

0.95

(0.037)

REF

1.50 – 1.75

(0.059 – 0.069)

0.35 – 0.55

(0.014 – 0.022)

0.35 – 0.50

(0.014 – 0.020)

FIVE PLACES (NOTE 2)

S5 SOT-23 0599

2.80 – 3.00

(0.110 – 0.118)

(NOTE 3)

1.90

(0.074)

REF

0.90 – 1.45

(0.035 – 0.057)

0.90 – 1.30

(0.035 – 0.051)

0.00 – 0.15

(0.00 – 0.006)

0.09 – 0.20

(0.004 – 0.008)

(NOTE 2)

2.60 – 3.00

(0.102 – 0.118)

NOTE:

1. DIMENSIONS ARE IN MILLIMETERS

2. DIMENSIONS ARE INCLUSIVE OF PLATING

3. DIMENSIONS ARE EXCLUSIVE OF MOLD FLASH AND METAL BURR

4. MOLD FLASH SHALL NOT EXCEED 0.254mm

5. PACKAGE EIAJ REFERENCE IS SC-74A (EIAJ)
