ICS9147-09

Absolute Maximum Ratings

Electrical Characteristics at 3.3V

Supply Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . 7.0V

Logic Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . GND 0.5V to VDD +0.5V

Ambient Operating Temperature . . . . . . . . . . . . 0°C to +70°C

Storage Temperature . . . . . . . . . . . . . . . . . . . . . . 65°C to +150°C

VDD = 3.0 3.7V, TA = 0 70

° C unless otherwise stated

Note 1: Parameter is guaranteed by design and characterization. Not 100% tested in production.

Stresses above those listed under Absolute Maximum Ratings may cause permanent damage to the device. These ratings are

stress specifications only and functional operation of the device at these or any other conditions above those listed in the

operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended

periods may affect product reliability.

DC Characteristics

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNITS

Input Low Voltage

VIL

Latched inputs and Fulltime inputs

0.2VDD

Input High Voltage

VIH

Latched inputs and Fulltime inputs

0.7VDD

Input Low Current

IIL

VIN = 0V (Fulltime inputs)

-28.0

-10.5

µA

Input High Current

IIH

VIN=VDD (Fulltime inputs)

-5.0

5.0

µA

Output Low Current

IOL1a

VOL = 0.8V; CPU, SDRAM IOAPIC, REF,

BUS; VDD2 = 3.3V

19.0

30.0

IOL1b

VOL = 0.8V; CPUL, IOAPIC; VDD2 = 2.5V

19.0

30.0

Output High Current

IOH1a

VOH = 2.0V; CPU, SDRAM IOAPIC, REF,

BUS; VDD2 = 3.3V

-26.0

-16.0

IOH1b

VOH = 2.0V; CPUL, IOAPIC; VDD2 = 2.5V

-12.5

-9.5

Output Low Current

IOL2

VOL = 0.8V; for fixed 24, 48

16.0

25.0

Output High Current

IOH2

VOH = 2.0V; for fixed 24, 48

-22.0

-14.0

Output Low Voltage

VOL1a

IOL = 10mA; CPU, SDRAM IOAPIC REF,

BUS;VDD2 = 3.3V

-0.3

0.4

VOL1b

IOL = 10mA; CPUL, IOAPIC; VDD2=2.5V

0.3

0.4

Output High Voltage

VOH1a

IOH = -10mA; CPU, SDRAM, IOAPIC,

REF, BUS; VDD = 3.3V

2.4

2.8

VOH1b

IOH = -10mA; CPUL, IOAPIC; VDD2=2.5V

1.95

2.1

Output Low Voltage

VOL2

IOL = 8mA; for fixed 24, 48MHz CLKs

0.3

0.4

Output High Voltage

VOH2

IOH = -8mA; for fixed 24, 48MHz CLKs

2.4

2.8

Supply Current

IDD

@66.6 MHz; all outputs unloaded

120

180

Power Down Current

Ipd

PD#=0

5.0

20.0

µA

Pull-up Resistor

Rpu

CPUSTOP#; PD#

Kohms
