MicroSmart Series
29
Programmable Logic Controllers
Input Usage Limits
FC5A-D16RK1/D16RS1
FC5A-D32K3/D32S3
FC4A-D40K3/D40S3
FC4A-D20K3/D20S3
FC4A-D20RK1/D20RS1
Input Voltage (V DC)
Input Voltage (V DC)
Input Voltage (V DC)
Input Voltage (V DC)
Ambient Temperature
40ºC
Ambient Temperature
40ºC
Ambient Temperature
40ºC
Ambient
Temperature
55ºC
Ambient
Temperature
55ºC
Ambient
Temperature
55ºC
Ambient Temperature
55ºC
I/O Simultaneous ON Ratio (%)
I/O Simultaneous ON Ratio (%)
I/O Simultaneous ON Ratio (%)
26.4
24.0
26.4
24.0
26.4
24.0
26.4
24.0
I/O Simultaneous ON Ratio (%)
0
50
100
0
50
100
0
50
100
0
50
100
All-in-One CPU
FC5A-C10R2
FC5A-C10R2C
FC4A-C10R2
FC4A-C10R2C
FC5A-C16R2
FC5A-C16R2C
FC4A-C16R2
FC4A-C16R2C
FC5A-C24R2
FC5A-C24R2C
FC4A-C24R2
FC4A-C24R2C
CAUTION: When using at an operating ambient tem-
perature above 40ºC, reduce the input voltage or the
quantity of I/O points that turn on simultaneously.
28.8
26.4
28.8
26.4
28.8
26.4
Input Voltage (V DC)
Input Voltage (V DC)
Input Voltage (V DC)
Ambient Temperature
55ºC
Ambient Temperature
45ºC
Ambient Temperature
45ºC
Ambient
Temperature
55ºC
Ambient
Temperature
55ºC
I/O Simultaneous ON Ratio (%)
I/O Simultaneous ON Ratio (%)
I/O Simultaneous ON Ratio (%)
0
50
100
0
50
100
0
50
100
Input Internal Circuit
Output Internal Circuit
Slim CPU
All-in-One CPU
Slim CPU
4.7 kΩ
FC4A: I0, I1, I6, I7
FC5A: I0, I1, I3, I4, I6, I7
COM
Input
Input
3.3 kΩ (FC5A)
1.8 kΩ (FC4A)
I0, I1
COM
Sink Output
Internal
Circuit
+V
Output
COM (–)
COM
Input
3.3 kΩ
FC4A: I2 to I5, I10 to I27
FC5A: I2, I5, I10 to I17
COM
Input
3.3 kΩ
I2 to I15
Source Output
Internal
Circuit
–V
Output
COM (+)
