Power Chip Shielded Inductors

PCS2D14

15

DCR

(

Ω)

Rated

Current

Allied

Part

Number

Inductance

(

µh)

Tolerance

(%)

Test

Freq.

PCS2D14-R47T-RC

PCS2D14-1R5T-RC

PCS2D14-1R8T-RC

PCS2D14-2R2T-RC

PCS2D14-2R7T-RC

PCS2D14-3R9T-RC

PCS2D14-5R6T-RC

PCS2D14-6R8T-RC

PCS2D14-8R2T-RC

PCS2D14-100T-RC

.47

1.5

1.8

2.2

2.7

3.9

5.6

6.8

8.2

10

30

100

0.040

0.063

0.075

0.094

0.106

0.138

0.188

0.213

0.281

0.294

2.00

1.80

1.65

1.50

1.35

1.10

0.95

0.85

0.80

0.70

ALLIED COMPONENTS INTERNATIONAL

714-665-1140

www.alliedcomponents.com

RoHS

PCS2D14-3R3T-RC

3.3

30

100

0.125

1.20

PCS2D14-4R7T-RC

4.7

30

100

0.169

1.00

(A)

KHz,1v

All specifications subject to change without notice.

REVISED 12/11/08

Irms

(A)

2.00

1.80

1.60

1.40

1.12

0.98

0.92

0.80

0.76

1.24

1.00

PCS2D14-120T-RC

12

30

100

0.394

0.62

Max

0.64

PCS2D14-4R1T-RC

4.1

30

100

0.169

1.00

Typ.

Features

• Shielded SMD Power Inductor

• Low DC resistance

• Ideal for DC-DC converter applications

• Low profile

Electrical

Inductance Range: .47µh to 12µh

Tolerance: 30% over entire range

Operating Temp: -35ºC ~ +100ºC

Rated Current: Current at which inductance

drop is equal to 35% typ.

Resistance to Soldering Heat

Pre-Heat 150ºC, 1 Min.

Solder Composition: Sn/Ag3.0/Cu0.5

Solder Temp: 260ºC +/- 5ºC for

10 sec. +/- 1 sec.

Test Equipment

(L): PM3260A / HP4284A / HP4285A

(RDC): Chen Hwa 502BC

Rated Current: HP4284A+HP42841A or

Chen Hwa 1061 + Chen Hwa 301A

Physical

Packaging: 1000 pieces per 7 inch reel.

Marking: 2 Character Alpha Code

∆ T=40ºC temp rise

Irms: current at which

Also, available in tighter tolerances

Dimensions:

Inches

(mm)
