Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.

Should a safety concern arise regarding this product, please be sure to contact us immediately.

Multilayer Ceramic Capacitors(100V, 200V Series)

– EC34 –

Rated voltage

DC 100 V

DC 200 V

Capaci-

tance

(pF)

Capacitance

Tolerance

Part No.

Dim.

T

(mm)

Temp.

Char.

Part No.

Dim.

T

(mm)

Temp.

Char.

BX7R

BX7R

220

±10 % (K)

or

±20 % (M)

ECJ2VB2A221

0.85

ECJ2VB2D221

0.85

330

ECJ2VB2A331

0.85

ECJ2VB2D331

0.85

470

ECJ2VB2A471

0.85

ECJ2VB2D471

0.85

680

ECJ2VB2A681

0.85

ECJ2VB2D681

0.85

1000

ECJ2VB2A102

0.85

ECJ2VB2D102

0.85

1500

ECJ2VB2A152

0.85

ECJ2VB2D152

0.85

2200

ECJ2VB2A222

0.85

ECJ2VB2D222

0.85

3300

ECJ2VB2A332

0.85

ECJ2VB2D332

0.85

4700

ECJ2VB2A472

0.85

ECJ2VB2D472

0.85

6800

ECJ2VB2A682

0.85

ECJ2FB2D682

1.25

10000

ECJ2VB2A103

0.85

ECJ2FB2D103

1.25

15000

ECJ2FB2A153

1.25

● Class 2

◆ Temperature Characteristics Code: B (Temperature Characteristics: B, X7R)

: Capacitance tolerance code.

Standard packaging quantity of Packaging Style Code “V” (T = 0.8 mm): 4,000 pcs./reel

Rated voltage

DC 100 V

Capaci-

tance

(pF)

Capacitance

Tolerance

Part No.

Dim.

T

(mm)

Temp.

Char.

CH

10 ±0.5 pF (D) ECJ1VC2A100D 0.8

15

±5 % (J)

or

±10 % (K)

ECJ1VC2A150

0.8

22

ECJ1VC2A220

0.8

33

ECJ1VC2A330

0.8

47

ECJ1VC2A470

0.8

68

ECJ1VC2A680

0.8

100

ECJ1VC2A101

0.8

● Class 1

◆ Temp. Char. Code: C (Temp. Char.: CH)

Rated voltage

DC 100 V

DC 200 V

Capaci-

tance

(pF)

Capacitance

Tolerance

Part No.

Dim.

T

(mm)

Temp.

Char.

Part No.

Dim.

T

(mm)

Temp.

Char.

BX7R

BX7R

220

±10 % (K)

or

±20 % (M)

ECJ1VB2A221

0.8

ECJ1VB2D221

0.8

330

ECJ1VB2A331

0.8

ECJ1VB2D331

0.8

470

ECJ1VB2A471

0.8

ECJ1VB2D471

0.8

680

ECJ1VB2A681

0.8

ECJ1VB2D681

0.8

1000

ECJ1VB2A102

0.8

ECJ1VB2D102

0.8

: Capacitance tolerance code.

Standard packaging quantity of Packaging Style Code “V” (T = 0.8 mm): 4,000 pcs./reel

● Class 2

◆ Temp. Char. Code: B (Temp. Char.: B, X7R)

● Class 1

◆ Temperature Characteristic Code: C (Temperature Characteristics: CH)

Rated voltage

DC 100 V

DC 200 V

Capaci-

tance

(pF)

Capacitance

Tolerance

Part No.

Dim.

T

(mm)

Temp.

Char.

Part No.

Dim.

T

(mm)

Temp.

Char.

CH

CH

10 ±0.5 pF (D) ECJ2VC2A100D 0.85

ECJ2VC2D100D 0.85

15

±5 % (J)

or

±10 % (K)

ECJ2VC2A150

0.85

ECJ2VC2D150

0.85

22

ECJ2VC2A220

0.85

ECJ2VC2D220

0.85

33

ECJ2VC2A330

0.85

ECJ2VC2D330

0.85

47

ECJ2VC2A470

0.85

ECJ2VC2D470

0.85

68

ECJ2VC2A680

0.85

ECJ2FC2D680

1.25

100

ECJ2VC2A101

0.85

ECJ2FC2D101

1.25

150

ECJ2VC2A151

0.85

ECJ2FC2D151

1.25

220

ECJ2VC2A221

0.85

ECJ2FC2D221

1.25

330

ECJ2VC2A331

0.85

ECJ2FC2D331

1.25

470

ECJ2VC2A471

0.85

680

ECJ2VC2A681

0.85

1000

ECJ2VC2A102

0.85

: Capacitance tolerance code : “ ” for “J” or “K”

Standard packaging quantity of Packaging Style Code “V” (T = 0.85 mm): 4,000 pcs./reel, “F” (T = 1.25 mm): 3,000 pcs./reel

Soldering method of dimension T>1 mm: Avoid flow soldering.

: Capacitance tolerance code : “ ” for “K” or “M”

Standard packaging quantity of Packaging Style Code “V” (T = 0.85 mm): 4,000 pcs./reel, “F” (T = 1.25 mm): 3,000 pcs./reel

Soldering method of dimension T>1 mm: Avoid flow soldering.

Apr. 2008

00
