1MD Series

Shielded Power Inductor

Accetek Electronics (Shenzhen) Co., Ltd.                        www.accetek.com                                         Ver.:1MD‐2012A

Accetek



2D09,2D11,2D14,2D18

3D11,3D14,3D16,3D18,3D28,4D18,4D28,5D18,5D28,6D28,6D38

XXX

A

B

D

C

I

I

J

H

XXX

A

B

C

I

I

J

H

D

8D28,8D38,8D43

Schematic

XXX

A

B

C

I

I

J

H

2



XXX = Inductance value

Case Size

Dimensions (mm)

1MD2D09

3.3

3.3

1.1

4.4

1.3

1.3

1.7

1MD2D11

3.3

3.3

1.3

4.4

1.3

1.3

1.7

1MD2D14

3.3

3.3

1.6

4.4

1.3

1.3

1.7

1MD2D18

3.3

3.3

2.1

4.4

1.3

1.3

1.7

1MD3D11

4.2

4.2

1.3

5.5

4.5

1.7

1.1

1MD3D14

4.2

4.2

1.6

5.5

4.5

1.7

1.1

1MD3D16

4.2

4.2

1.8

5.5

4.5

1.7

1.1

1MD3D18

4.2

4.2

2.1

5.5

4.5

1.7

1.1

1MD3D28

4.2

4.2

3.2

5.5

4.5

1.7

1.1

1MD4D18

5.0

5.0

2.0

6.9

5.3

1.9

1.5

1MD4D28

5.0

5.0

3.0

6.9

5.3

1.9

1.5

1MD5D18

6.0

6.0

2.0

8.2

6.3

2.1

2.0

1MD5D28

6.0

6.0

3.0

8.2

6.3

2.1

2.0

1MD6D28

7.0

7.0

3.0

9.5

7.3

2.6

2.0

1MD6D38

7.0

7.0

4.0

9.5

7.3

2.6

2.0

1MD8D28

10.1

8.3

3.0

/

2.8

2.0

6.1

1MD8D38

10.1

8.3

4.0

/

2.8

2.0

6.1

1MD8D43

10.1

8.3

4.5

/

2.8

2.0

6.1
