Specifications

Serial Interface

- Serial speeds 75bps to 230kbps

- DB9 connector

- Flow Control : H/W and S/W

- Signals : RS232 / Rx,Tx,RTS,CTS,DSR,DTR,DCD,GND

RS422 / Tx+,Tx-,Rx+,Rx-,RTS+,RTS-,CTS+,CTS-

RS485 / 2/4-wire

- Surge protector equipped for each serial port

Network Interfaces

- 10/100 Base-T Ethernet with RJ45 Ethernet connector

- Supports static and dynamic IP address

Protocols

- ARP, IP/ICMP, TCP, UDP

- Telnet/SSH

- DNS, Dynamic DNS, HTTP, SMTP, DHCP,

- SNMP v1 & v2, SSL v3

- Serial Port Access protocol : TCP, UDP, SSL v3, RFC-2217

Ethernet modem

- Full AT command set support

Security

- SSH, SSL, HTTPS

- IP address filtering

- Data Encryption

Management

- Web, Console, Telnet / SSH

- HelloDevice Manager software

O/S support : Windows 98/ME/NT/2000/XP

Logging

- Versatile system logging support for all system events

- Serial port data logging

Firmware

- Upgrade using console, telnet/SSH and web

Diagnostic LED

- PS110 : Power, Link, Serial Rx/Tx for each serial port

- PS410 : Power, Link, Act, Serial Rx/Tx for each serial port

- PS810 : Power, Ready, Link, Act, Serial Rx/Tx for each

serial port

Power

- PS110 : 9~30VDC, 300mA@9VDC

- PS410 : 9~30VDC, 500mA@9VDC

- PS810 : 100~240VAC, 50/60Hz, 0.24A

Environmental

- Operating temperature : 0˚C to 50˚C

- Storage temperature : -20˚C to 66˚C

- Humidity : 90% Non-condensing

Physical properties

- PS110 : 114 x 82 x 26 (mm)

4.48 x 3.22 x 1.02 ( in.) / 300g

- PS410 : 119 x 227 x 27 (mm)

4.68 x 8.94 x 1.06 ( in.) / 750g

- PS810 : 119x 437 x 44 (mm)

4.69 x 17.20 x 1.73 ( in.) / 1.56kg

19" rack mountable

Certification

- FCC(A), CE, MIC

Warranty

- 5-year limited warranty

U.S. / Canada / South America

Tel : +1 (408) 573-7425 Fax: +1 (408) 907-3738

Toll Free (US/Canada): 1-8668-US-SENA (1-866-887-7362)

EU / Africa

Tel : +33 (0) 1 53 53 16 29 Fax: +33 (0) 1 70 24 70 90

Asia / Pacific

Tel : +82-2-571-8283 Fax: +82-2-573-7710

Contact us via E-mail

General Information : info@sena.com

Sales & Distribution : sales@sena.com

Technical Support : support@sena.com

Ordering Information

www.sena.com

Serial Device Server,

HelloDevice Pro Series,

PS110/410/810

PS110

HelloDevice Pro 110 single-port serial device server

PS410

HelloDevice Pro 410 4-port serial device server

PS810

HelloDevice Pro 810 8-port serial device server

Includes

- Quick Start Guide

- External 110V(or 230V) power supply or power cord

- Serial data cable

- CD-ROM

Optional Accessories

- DIN-Rail mount kit for the PS110/410
