Ultra-small U-shaped Micro Photoelectric Sensor

PM-24 SERIES

452

Selection

Guide

U-shaped

Convergent

Reflective

PM-64

PM-24

PM-44/

PM-54

FIBER

SENSORS

LASER

SENSORS

PHOTO-

ELECTRIC

SENSORS

MICRO

PHOTO-

ELECTRIC

SENSORS

AREA

SENSORS

LIGHT

CURTAINS

PRESSURE /

FLOW

SENSORS

INDUCTIVE

PROXIMITY

SENSORS

PARTICULAR

USE

SENSORS

SENSOR

OPTIONS

SIMPLE

WIRE-SAVING

UNITS

WIRE-SAVING

SYSTEMS

MEASURE-

MENT

SENSORS

STATIC

CONTROL

DEVICES

ENDOSCOPE

LASER

MARKERS

PLC /

TERMINALS

HUMAN

MACHINE

INTERFACES

ENERGY

CONSUMPTION

VISUALIZATION

COMPONENTS

MACHINE

VISION

SYSTEMS

CURING

SYSTEMS

Type

Appearance (mm in)

Sensing range

Model No. (Note)

Output

Output operation

0.472

0.866

6 0.236

5 mm 0.197 in

(fixed)

PM-K24

NPN open-collector

transistor

Incorporated with 2 outputs:

Light-ON / Dark-ON

PM-K24P

PNP open-collector

transistor

PM-K24-R

NPN open-collector

transistor

12 0.472

10.5

0.413

13.4

0.528

PM-L24

NPN open-collector

transistor

PM-L24P

PNP open-collector

transistor

PM-L24-R

NPN open-collector

transistor

10.5 0.413

0.472

13.4

0.528

PM-F24

NPN open-collector

transistor

PM-F24P

PNP open-collector

transistor

PM-F24-R

NPN open-collector

transistor

10.5 0.413

0.472

13.4

0.528

PM-R24

NPN open-collector

transistor

PM-R24P

PNP open-collector

transistor

PM-R24-R

NPN open-collector

transistor

0.630

13.4

0.528

6 0.236

PM-U24

NPN open-collector

transistor

PM-U24P

PNP open-collector

transistor

PM-U24-R

NPN open-collector

transistor

3 m 9.843 ft cable length type

3 m 9.843 ft cable length type (standard: 1 m 3.281 ft) is also available. (excluding flexible cable type and PNP output type)

When ordering this type, suffix “

-C3” to the model No.

(e.g.) 3m 9.843 ft cable length type of

PM-K24 is “PM-K24-C3”.

OPTIONS

Designation

Model No.

Description

Mounting screw

MS-M2

Mounting screw with washers for the ultra-small type sensor

(50 pcs. lot). It can mount securely as it is spring washer

attached.

Mounting screw

•MS-M2

Note: The suffix “

-R” indicates a flexible cable type.

ORDER GUIDE

Starting point

The starting point can be sensed by

making a slit in the rotating body.

APPLICATIONS

Sensing the starting point on a

rotating body
