BEZEL FOR

DOTMATRIX MODULES

Issue 1.2012

Zeppelinstraße 19 · D-82205 Gilching · Tel. +49-(0)8105-778090 · Fax: +49-(0)8105-778099 · www.lcd-module.de · info@lcd-module.de

BEZELS EA 017-XXU SERIES

These bezels give your equipment a professional design without extra tooling. The bezels are made

of black ABS-material (UL listed) with a scratch-resistant and structured surface. They include a snap-

in appliance for easy mounting of different 1 mm windows. They are available with glass or

acrylicglass window, both clear or antiglare version. The bezels are glued into the frontpanel of your

equipment.

bezel version

ordering information

without window

EA 017-xxU

clear acrylicglass

EA 017-xxUK

antiglare acrylicglass

EA 017-xxUKE

clear glass

EA 017-xxUG

antiglare glass

EA 017-xxUGE

BEZELS EA 017-XX SERIES

These bezels are similar in design (not UL listed), the surface is mat black coated. Acrylicglass

windows are available clear or antiglare.

bezel version

ordering information

without window

EA 017-xx

clear acrylicglass

EA 017-xxK

antiglare acrylicglass

EA 017-xxKE

EA 017-xxU
