GS1010FLK-CA2F-R datasheet(2/3 Pages) UTC

2 / 3 page

GS1010FL

Preliminary

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

VER.a



ABSOLUTE MAXIMUM RATINGS (TA=25°C, unless otherwise specified)

PARAMETER

SYMBOL

RATINGS

UNIT

Repetitive Peak Reverse Voltage

VRRM

1000

Maximum RMS Voltage

VRMS

700

Maximum DC Blocking Voltage

VDC

1000

Rectified Current (Average) Half Wave Rectification with

Resist. Load at TA=25°C (Note 1)

1.0

Surge Forward Current at t<1s, TJ=25°C

IFSM

Junction Temperature

-55~+150

°C

Storage Temperature

TSTG

-55~+150

°C

Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. Measured at 1MHz and applied reverse voltage of 0V D.C.



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

θJA

200

°C/W



ELECTRICAL CHARACTERISTICS (TA=25°C, unless otherwise specified)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Forward Voltage

IF=1.0A

1.1

Leakage Current

VR=1000V, TJ=25°C

μA

VR=1000V, TJ=100°C

μA

Junction Capacitance (Note)

4.0

Note: Measured at 1MHz and applied reverse voltage of 4.0V D.C.
