ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

[GND-0.5]~+6.0

V

ESD Diode Forward Current (One Diode Conducting at a Time)

10

mA

DC Voltage at Inputs

VIDEO_1, VIDEO_2, VIDEO_3

V

DDC_IN1, DDC_IN2

[GND-0.5]~6.0

V

DDC_OUT1, DDC_OUT2

[GND-0.5]~6.0

V

SYNC_IN1, SYNC_IN2

V

Operating Temperature Range

-40~+85

°C

Storage Temperature

-40~+150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

10

μA

10

μA

50

μA

3.0 V, SYNC Outputs Unloaded

2.0

mA

ESD Diode Forward Voltage

1.0

V

Logic High Input Voltage

2.0

V

Logic Low Input Voltage

0.6

V

Logic High Output Voltage

4.85

V

Logic Low Output Voltage

0.15

V

SYNC Driver Output Resistance

(CCVGA7C9−00 only)

3.0V

65

Ω

SYNC Driver Output Resistance

(CCVGA7C9−02 only)

3.0V, (Note 2)

15

Ω

Logic High Output Voltage

(CCVGA7C9−02 only)

(Note 2)

2.0

V

Logic Low Output Voltage

(CCVGA7C9−02 only)

0.8

V

Input Current VIDEO Inputs

±1

μA

SYNC_IN1, SYNC_IN2 Inputs

±1

μA

Level Shifting N−MOSFET ”OFF”

State Leakage Current

10

μA

10

μA

Voltage Drop Across Level-Shifting

N-MOSFET when “ON”

0.18

V

VIDEO Input Capacitance

(Note 3)

4

pF

4.5

pF

SYNC Driver L => H Propagation

Delay

12

ns
