Revision history

STBB2

24/25

DocID022745 Rev 9

Revision history

Table 11. Document revision history

Date

Revision

Changes

27-Jan-2012

First release.

27-Mar-2012

Datasheet promoted from preliminary data to production data.

Removed: order code STBB2J28-R Table 1 on page 1.

09-May-2012

Modified: marking BB2 Table 1 on page 1, description pin B4 and D4 Table 5

on page 6.

26-Jul-2012

Modified: C2 value Table 2 on page 3.

Updated: Figure 20, Figure 21 and Figure 22 on page 21.

19-Sep-2012

Modified: Figure 2 on page 3.

06-Mar-2013

Added: new order code STBB2J33-R Table 1 on page 1.

17-Dec-2013

Changed order code from the STBB2J33-R to the STBB2J30-R in Table 1:

Device summary and in Table 9: Output selection.

Changed VOPP-PS typ. value from 100 to 130 in Table 6: Electrical

characteristics.

Minor text changes.

20-Jan-2014

Updated mechanical data.

12-Feb-2014

Updated Features and Description in cover page.

Changed typ. and max. values of VUVLO parameter in Table 6.

Changed VIN min. value in Table 6.

Changed VIN test conditions of Iq parameter in Table 6.

Changed IPK min. value in Table 6.

Updated Table 7.
