A T C H V R S E R I E S R E S I S T I V E P R O D U C T S

ATC HVR Series Resistors

Features:

• EIA 0402 Case Size

• Power Rating: 125 mW

• Operating Temperature:

-40°C to +125°C

• 100% Laser Trimming for

Tight Tolerances

ATC // AVX Thin Film Technologies is pleased to introduce

the HVR Series next generation of surface mount High

Value Resistors. This product was designed with our pro-

prietary Glass Sandwich Flexiterm® Technology, (GSFT).

The Flexiterm® is a surface mountable automotive qual-

ified termination that adds an extra margin against

damage due to flexture during installation.

The HVR Series has been designed with high quality

selected materials that yield excellent performance.

This product is ideal for use in applications requir-

ing surface mountable small outline EIA resistors.

ATC # 001-1110

Rev A, 5/12

Resistor

Detail

Outline

EIA 0402

Package

Glass wafer sandwich

Maxiumum Voltage

1 KV

Resistance Value Range

From 2.2 M

Ω

to 20 M

Ω

Termination

Flexiterm® (Ag/Epoxy), plated

Power Rating

125 mW

Operating Temperature Range

-40°C to +125°C

Tolerances

1%, 5%

Specifications

Applications:

• Multi Chip Module (MCM)

• Bias Networks

• Test and Measurement Equipment

• Aerospace

• Medical

• Automotive
