Specifications are subject to change without notice.

Customers should verify actual device performance in their specific applications.

REV. 05/11

SRP1204 Series - Shielded Power Inductors

Packaging Specifications

26.0 - 0

(1.02 - 0)

30.4

(1.197)

2.0 ± 0.5

(.079 ± .020)

50.0 - 0

(1.97 - 0)

330.0

(13.00)

DIA.

13.0

(.51)

DIA.

13.0

(.51)

DIA.

21.0 ± 0.8

(.827 ± .031)

EMBOSSED

CARRIER

EMBOSSED

CAVITY

0.10

(.004)

THICKNESS

MAX.

DIMENSIONS:

MM

(INCHES)

4.0

(0.157)

16.0

(0.630)

R50

R50

R50

R50

R50

END

START

USER DIRECTION OF FEED

200

(7.874)

NO COMPONENT

MIN.

MIN.

NO COMPONENT

COMPONENTS

400

(15.748)

Soldering Profile

25

75

125

175

225

275

0

50

100

150

200

250

300

Time (Seconds)

120 -150 seconds

60 seconds

maximum

260 °C peak

190°C

150 °C

220 °C

Ramp Down

5 °C/second

<1> 255 °C

<1> Maximum of 10 seconds

between +255 °C and +260 °C

Ramp Up

4 °C/second maximum

10 seconds minimum
