1 / 2 page  http://www.adlinktech.com/cPCI/ Specifications Processor & System CPU μFC-PGA Intel® Core™2 Duo 2.2GHz (T7500), 4MB L2 cache, FSB 800MHz μFC-BGA Intel® Core™2 Duo LV 1.6GHz (L7500), 4MB L2 cache, FSB 800MHz μFC-PGA Intel® Celeron® 2.0GHz (550), 1MB L2 cache, FSB 533MHz Chipset Intel® GME965 with ICH8M RAM Dual Channel DDR2-667 unbuffered memory with two SO-DIMM sockets, up to 4GB capacity BIOS AMIBIOS®8 16Mbit SPI Flash memory CompactPCI Bus 32-bit/33 MHz CompactPCI® Bus PICMG Standards PICMG® 2.0 CompactPCI® R3.0 PICMG® 2.1 Hot Swap R2.0 Connectivity Ethernet Two PCI-Express Intel® 82573L Gigabit Ethernet controllers Two GbE egress ports, one configurable to rear by software Graphics Integrated in GME965 One analog VGA port on front panel, supports up to 32bit, 2048x1536 resolution @ 75Hz refresh rate One DVI-D front port USB Maximum six USB 2.0 ports Four front panel USB 2.0 ports, two USB 2.0 ports on RTM PS/2 One PS/2 KB/MS Combo Port Serial Port One RJ-45 RS-232 port on front panel, and one DB-9 RS-232 (Tx, Rx only) port on rear panel Storage SBC One SATA port for 2.5” hard drive onboard One CompactFlash socket RTM Two 7-pin SATA ports on RTM for external hard drives Operating System OS Microsoft Windows® XP Professional Microsoft Windows® Vista Enterprise Microsoft Windows® 7 Fedora™ Core 7 Fedora™ 9 Red Hat Enterprise Linux 6 Wind River VxWorks 6.6, 6.7 Miscellaneous LED Power, WDT Battery Coin cell lithium battery onboard for RTC CMOS RAM Hardware Monitor Integrated in Super I/O IT8712F, monitors CPU temperature, system temperature, Vcore and DC voltages Watchdog Timer Integrated in super I/O IT8712F, two stage watchdog timer, 1 to 15300 sec. Mechanical & Environmental Form Factor 3U 4HP/8HP CompactPCI® 100 mm x 160mm (L x W) Operating Temp. 0°C to +60°C standard (with forced air flow) Storage Temp. -40°C to +85°C Rel. Humidity 90% @ 60°C (non-condensing) Shock 15G peak-to-peak, 11ms duration, non-operating Vibration 88Grms, 5-500Hz, each axis, operating IEC68-2-64 standard Power Consumption Core™2 Duo 2.2GHz (T7500), 2x 2GB SODIMM under Windows® XP with 100% CPU loading Current (A) Power (W) 5V 6.2 31.0 3.3V 0.7 2.3 Total 33.3 Weight Net weight 602.5g in dual slot with heatsink Safety & EMI Certifications CE, FCC Class A Low Power 3U CompactPCI® Intel® Core™2 Duo Processor Blade with Dual Independent Display cPCI-3965 Series Features Low power Intel® Core™2 Duo 2.2GHz Dual Channel DDR2-667 SODIMM, up to 4GB VGA+DVI independent display Two PCI-Express Gigabit Ethernet egress ports Serial ATA and CompactFlash storage options LAN DVI-D USB KB/MS COM VGA USB cPCI-3965 cPCI-3965D |
