LT1780/LT1781

PACKAGE DESCRIPTIO

Dimensions in inches (millimeters) unless otherwise noted.

SW Package

16-Lead Plastic Small Outline (Wide 0.300)

(LTC DWG # 05-08-1620)

S16 (WIDE) 0396

NOTE 1

0.398 – 0.413*

(10.109 – 10.490)

16

15

14

13

12

11

10

9

1

23

4

5

6

78

0.394 – 0.419

(10.007 – 10.643)

0.037 – 0.045

(0.940 – 1.143)

0.004 – 0.012

(0.102 – 0.305)

0.093 – 0.104

(2.362 – 2.642)

0.050

(1.270)

TYP

0.014 – 0.019

(0.356 – 0.482)

TYP

0

° – 8° TYP

NOTE 1

0.009 – 0.013

(0.229 – 0.330)

0.016 – 0.050

(0.406 – 1.270)

0.291 – 0.299**

(7.391 – 7.595)

× 45°

0.010 – 0.029

(0.254 – 0.737)

NOTE:

1. PIN 1 IDENT, NOTCH ON TOP AND CAVITIES ON THE BOTTOM OF PACKAGES ARE THE MANUFACTURING OPTIONS.

THE PART MAY BE SUPPLIED WITH OR WITHOUT ANY OF THE OPTIONS

DIMENSION DOES NOT INCLUDE MOLD FLASH. MOLD FLASH SHALL NOT EXCEED 0.006" (0.152mm) PER SIDE

DIMENSION DOES NOT INCLUDE INTERLEAD FLASH. INTERLEAD FLASH SHALL NOT EXCEED 0.010" (0.254mm) PER SIDE

*

**
