6 / 20 page

ADN8831

Data Sheet

Rev. A | Page 6 of 20

ABSOLUTE MAXIMUM RATINGS

Absolute maximum ratings at 25°C, unless otherwise noted.

Table 2.

Parameter

Rating

Supply Voltage

6 V

Input Voltage

GND to VS + 0.3 V

Storage Temperature Range

−65°C to +150°C

Junction Temperature

125°C

Lead Temperature (Soldering, 60 sec)

300°C

Stresses above those listed under Absolute Maximum Ratings may

cause permanent damage to the device. This is a stress rating

only; functional operation of the device at these or any other

conditions above those indicated in the operational section of this

specification is not implied. Exposure to absolute maximum

rating conditions for extended periods may affect device

reliability.

THERMAL CHARACTERISTICS

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 3. Thermal Resistance

Package Type

θJA

θJC

Unit

32-lead LFCSP (ACPZ)

33.4

1.02

°C/W

ESD CAUTION
