PIC18F2585/2680/4585/4680

DS39625C-page 420

Preliminary

Supply Current (IDD)(2,3)

PIC18LFX585/X680

6.10

8.40

μA

-40°C

VDD = 2.0V

FOSC = 31 kHz

(RC_IDLE mode,

Internal oscillator source)

6.70

8.40

μA

+25°C

7.40

22.0

μA

+85°C

PIC18LFX585/X680

9.60

12.00

μA

-40°C

VDD = 3.0V

11.00

12.00

μA

+25°C

12.00

33.00

μA

+85°C

All devices

20.00

28.00

μA

-40°C

VDD = 5.0V

22.00

28.00

μA

+25°C

24.00

33.00

μA

+85°C

PIC18FX585/X680

84.00

200.00

μA

+125°C

PIC18LFX585/X680 300.00 390.00

μA

-40°C

VDD = 2.0V

FOSC = 1 MHz

(RC_IDLE mode,

Internal oscillator source)

320.00 390.00

μA

+25°C

330.00 390.00

μA

+85°C

PIC18LFX585/X680 450.00 550.00

μA

-40°C

VDD = 3.0V

470.00 550.00

μA

+25°C

490.00 550.00

μA

+85°C

All devices

0.84

1.10

-40°C

VDD = 5.0V

0.88

1.10

+25°C

0.90

1.10

+85°C

PIC18FX585/X680

2.80

3.20

+125°C

PIC18LFX585/X680

0.76

1.10

-40°C

VDD = 2.0V

FOSC = 4 MHz

(RC_IDLE mode,

Internal oscillator source)

0.79

1.10

+25°C

0.81

1.10

+85°C

PIC18LFX585/X680

1.20

1.50

-40°C

VDD = 3.0V

1.30

1.50

+25°C

1.30

1.50

+85°C

All devices

2.20

2.70

-40°C

VDD = 5.0V

2.30

2.70

+25°C

2.30

2.70

+85°C

PIC18FX585/X680

4.70

5.50

+125°C

27.2

DC Characteristics:

Power-Down and Supply Current

PIC18F2585/2680/4585/4680 (Industrial)

PIC18LF2585/2680/4585/4680 (Industrial) (Continued)

PIC18LF2585/2680/4585/4680

(Industrial)

Standard Operating Conditions (unless otherwise stated)

Operating temperature

-40°C

≤ TA ≤ +85°C for industrial

PIC18F2585/2680/4585/4680

(Industrial, Extended)

Standard Operating Conditions (unless otherwise stated)

Operating temperature

-40°C

≤ TA ≤ +85°C for industrial

-40°C

≤ TA ≤ +125°C for extended

Param

No.

Device

Typ

Max

Units

Conditions

Legend:

Shading of rows is to assist in readability of the table.

Note

The power-down current in Sleep mode does not depend on the oscillator type. Power-down current is measured with the

part in Sleep mode, with all I/O pins in high-impedance state and tied to VDD or VSS and all features that add delta current

disabled (such as WDT, Timer1 Oscillator, BOR, etc.).

The supply current is mainly a function of operating voltage, frequency and mode. Other factors, such as I/O pin loading

and switching rate, oscillator type and circuit, internal code execution pattern and temperature, also have an impact on

the current consumption. The test conditions for all IDD measurements in active operation mode are:

OSC1 = external square wave, from rail-to-rail; all I/O pins tri-stated, pulled to VDD;

MCLR = VDD; WDT enabled/disabled as specified.

For RC oscillator configurations, current through REXT is not included. The current through the resistor can be estimated

by the formula Ir = VDD/2REXT (mA) with REXT in k

Ω.

Standard low-cost 32 kHz crystals have an operating temperature range of -10°C to +70°C. Extended temperature

crystals are available at a much higher cost.
