Preliminary

DS39625C-page 417

PIC18F2585/2680/4585/4680

27.1

DC Characteristics:

Supply Voltage

PIC18F2585/2680/4585/4680 (Industrial)

PIC18LF2585/2680/4585/4680 (Industrial)

PIC18LF2585/2680/4585/4680

(Industrial)

Standard Operating Conditions (unless otherwise stated)

Operating temperature

-40°C

≤ TA ≤ +85°C for industrial

PIC18F2585/2680/4585/4680

(Industrial, Extended)

Standard Operating Conditions (unless otherwise stated)

Operating temperature

-40°C

≤ TA ≤ +85°C for industrial

-40°C

≤ TA ≤ +125°C for extended

Param

No.

Symbol

Characteristic

Min

Typ

Max

Units

Conditions

VDD

Supply Voltage

D001

PIC18LFX585/X680

2.0

—

5.5

PIC18FX585/X680

4.2

—

5.5

D002

VDR

RAM Data Retention

Voltage(1)

1.5

—

D003

VPOR

VDD Start Voltage

to ensure internal

Power-on Reset signal

—

0.7

See section on Power-on Reset for details

D004

SVDD

VDD Rise Rate

to ensure internal

Power-on Reset signal

0.05

—

V/ms See section on Power-on Reset for details

VBOR

Brown-out Reset Voltage

PIC18LFX585/X680

D005

BORV1:BORV0 = 11

2.00

2.05

2.16

BORV1:BORV0 = 10

2.65

2.79

2.93

All Devices

BORV1:BORV0 = 01

4.11

4.33

4.55

BORV1:BORV0 = 00

4.36

4.59

4.82

Legend:

Shading of rows is to assist in readability of the table.

Note

This is the limit to which VDD can be lowered in Sleep mode, or during a device Reset, without losing RAM data.
